LOGISYS LG-T300 Industrial PC
Features
- Active cooling design with dual centrifugal fans
- Intel® Alder Lake S/Raptor Lake S LGA1700 Processors up to 65W Base TDP
- Intel Q670E Chipset
- 1 × 2.5Gb Ethernet port
- 6 × USB 3.2 ports
- 2 × DisplayPort
- 4 × M.2 M-Key 2280 slots for PCIe SSDs
- 3 × M.2 M-key 2230 slots
- Power Input: 12V DC, 84W
- Optional 13V~48V DC, 120W
- Standard-height Size 153 × 250 × 48mm (W × D × H) (6.02” x 9.84” x 1.89”)
Specifications
Processor
Supports Intel® Alder Lake S/Raptor Lake S (LGA1700) Processors up to 65W Base TDP
Memory
Support 1 DDR5-4800 non-ECC SODIMM, total memory size up to 32GB
Chipset
Intel Q670E
Display
Integrated Intel UHD graphics 710, 730 or 770 in processor
2 × DisplayPort outputs
Audio
Realtek ALC897 high definition audio CODEC
LAN
1 × Built-in Intel i226-IT 2.5Gbps Ethernet Controller
USB
6 × USB 3.2 ports (backward compatible with USB 2.0)
BIOS & Hardware Monitor
UEFI BIOS
CPU temperature, cooling fan speed and system voltages
Heat Dissipation
Active cooling design with dual centrifugal fans and heatsink
Power Supply
12 V DC via barrel jack (7 A / 84 W)
Expansion
- 4 × M.2 M-Key 2280 slots for PCIe SSDs (2 PCIe 4.0 x4, 2 PCIe 3.0 x4)
- 3 × M.2 M-Key 2230 slots (3 PCIe 3.0 x1)
- 1 × Parallel port header
IO Ports, Switch and Jumpers
Front Panel:
- 4 × USB 3.2 ports (compatible with USB 2.0 devices)
- 1 × Mic-in (3.5 mm)
- 1 × Headphone out (3.5 mm)
- 1 × RS-232 B port
- Power on/off button
- Reset button
- Power LED
- 2 × Antenna holes
- Optional 1 × Parallel Port
Rear Panel:
- 2 × DisplayPort
- 1 × RS-232 A port
- 1 × RJ45 2.5Gb Ethernet
- 2 × USB 3.2 ports
- 1 × Barrel type DC power jack, support 12V power input
- Optional terminal block power jack, support 13 ~ 48V power input
- Optional 1 × Audio Line Out (3.5mm)
- Optional remote power switch socket
- Optional PS/2 keyboard port
Dimension
Standard-height Size
153mm × 250mm × 48mm (WxDxH) (6.02” x 9.84” x1.89”)
